FAR M-CDC
Anechoic Chamber by Albatross Projects GmbH (3 more products)
Download Datasheet
Request Quote
Note: Your Quotation Request will be directed to Albatross Projects GmbH.
The FAR M-CDC from Albatross Projects GmbH is a Anechoic Chamber with Frequency 30 MHz to 18 GHz, Quiet Zone(Dia) 1 m. More details for FAR M-CDC can be seen below.
Product Specifications
Product Details
- Part Number :FAR M-CDC
- Manufacturer :Albatross Projects GmbH
- Description :Fully Anechoic 3m Chamber
General Parameters
- Type :Fully Anechoic
- Test Distance :3 m
- Frequency :30 MHz to 18 GHz
- EMC Standards :ANSI C63.4, CISPR 16-1-4, EN 55016-1-4, IEC 61000-4-3, EN 61000-4-3
- Quiet Zone(Dia) :1 m
- Field Uniformity Area :1.5 x 1.5 m
- Absorber :Hybrid
- Filters :one filter 3 phase 32 A for EUT supply and one 2 phase 16 A for internal use
- Application Industry :Commercial
- Lightning :Emergency and Signal lamps
- Shielded Panel Type :Pan
- Waveguide Vent :0.33 x 0.33 m
- Door/Gate :1.2 x 2.05 m
- Connectors :N Type, SMA
- Internal Dimensions :6.6 x 1.97 x 1.86 m
- External Dimensions :7.3 x 7.3 x 3.16 m
Technical Documents
- Datasheet
