CWS 1000CM
Surge Generator by 3Ctest (21 more products)
Request Quote
Note: Your Quotation Request will be directed to 3Ctest.
The CWS 1000CM from 3Ctest is a Surge Generator with Output Voltage Level 0.5 to 10 kV, Output Current Range 0.25 to 5 kA, Supply Voltage 110 to 220 VAC. More details for CWS 1000CM can be seen below.
Product Specifications
Product Details
- Part NumberCWS 1000CM
- Manufacturer3Ctest
- DescriptionCombination Wave Surge Immunity Test Simulator
General Parameters
- Surge WaveformWaveform 1.2/50 µs, Waveform 8/20 µs, Waveform 10/700 µs, Waveform 5/320 µs
- Surge Repetition1 to 999 times
- Output Voltage Level0.5 to 10 kV
- Output Current Range0.25 to 5 kA
- Supply Voltage110 to 220 VAC
- Interval Time5 to 99 s
- EMC StandardsIEC 61000-4-5, IEC 61643-1
- Fuse Type6 A
- Impedance500 Ohms
- InterfaceEthernet, RJ45
- ApplicationsIT, Military, Telecom, Avionics, Medical, New Energy, TV Broadcasting, New Energy Automotive, Railway
- Dimensions19”, 4U
- Weight40 kg
- Operating Temperature15 to 35 Degree C
