ML2437A
Power Meter by Anritsu (3 more products)The ML2437A from Anritsu is a Power Meter with Frequency 100 kHz to 65 GHz, Output Power 1 mW (0 dBm), Dynamic Range 90 dB, Supply Voltage 85 to 240 VAC, Measurement Speed 600 readings/sec. More details for ML2437A can be seen below.
Product Specifications
Product Details
- Part NumberML2437A
- ManufacturerAnritsu
- DescriptionSingle-Channel Power Meter
General Parameters
- Frequency100 kHz to 65 GHz
- Channels1 Channel
- Output Power1 mW (0 dBm)
- Dynamic Range90 dB
- Supply Voltage85 to 240 VAC
- Output Frequency50 MHz
- Impedance50 Ohms
- Instrument Accuracy0.005
- InterfaceGPIB, LAN, RS-232
- Power Consumption40 VA
- RangingAutomatic, Manual
- Time Resolution5 uS
- Video Bandwidth100 kHz
- DisplayMonochrome LCD, with backlight and adjust- able contrast
- Display UnitsWatt, %, Volts, dBm, dB, dBµV, dBmV, dBr
- Display Offset-199.99 dB to +199.99 dB
- Display Resolution0.1 dB to 0.001 dB
- VSWR1.12:1
- Measurement Speed600 readings/sec
- ConnectorsN Type, N Type - Female
- Dimensions223 x 150 x 390 mm
- Weight3 kg
- Operating Temperature0 to 40 Degree C
- Storage Temperature-40 to 70 Degree C
Technical Documents
- Datasheet
