FPA-2

EMC Pre-Amplifier by Frankonia Germany EMC Solutions GmbH (5 more products)
Request Quote

Note: Your Quotation Request will be directed to Frankonia Germany EMC Solutions GmbH.

The FPA-2 from Frankonia Germany EMC Solutions GmbH is a EMC Pre-Amplifier with Frequency 9 kHz to 2 GHz, Gain 30 dB, P1dB (dBm) -20 dBm(87 dBμV), P1dB (W) 0.00001 W, Input Power -20 dBm(87 dBμV). More details for FPA-2 can be seen below.

Product Specifications

Product Details

  • Part Number :
    FPA-2
  • Manufacturer :
    Frankonia Germany EMC Solutions GmbH
  • Description :
    EMC Pre-amplifier from 9 kHz to 2 GHz

General Parameters

  • Frequency :
    9 kHz to 2 GHz
  • Gain :
    30 dB
  • Noise Figure :
    2.5 dB
  • P1dB (dBm) :
    -20 dBm(87 dBμV)
  • P1dB (W) :
    0.00001 W
  • Input Power :
    -20 dBm(87 dBμV)
  • Type :
    Pre-Amplifier
  • VSWR :
    2.00:1
  • Input VSWR :
    2.00:1
  • Output VSWR :
    2.00:1
  • Impedance :
    50 Ohms
  • Current :
    120 mA
  • DC Voltage :
    12 V(±2 V)
  • Package Type :
    Module with Connector
  • Connectors :
    N Type - N Type - Male
  • Dimensions :
    82 x 38 x 27 mm
  • Weight :
    150 g
  • Applications :
    General purpose
  • Note :
    ESD protection : Yes, Amplitude flatness : ±3 dB
View more details on the manufacturer's website
