EFT 500G
EFT / Burst Generator by 3Ctest (3 more products)
Request Quote
Note: Your Quotation Request will be directed to 3Ctest.
The EFT 500G from 3Ctest is a EFT / Burst Generator with Burst Voltage 0.25 to 4.8 kV, Burst Duration 0.075 to 750 mS, Pulse Duration 50 nS. More details for EFT 500G can be seen below.
Product Specifications
Product Details
- Part Number :EFT 500G
- Manufacturer :3Ctest
- Description :High Voltage High-power EFT/Burst Test
General Parameters
- EMC Standards :IEC/EN 61000-4-4, IEC 61000-6-1, IEC 61000-6-2, GB/T 17626.4
- Functions :EFT / Burst
- Waveforms :5/50 ns
- Polarity :Positive, Negative, Alternate
- Burst Voltage :0.25 to 4.8 kV
- Burst Duration :0.075 to 750 mS
- Pulse Duration :50 nS
- Burst Time :1 to 9999 mS
- Rise Time :5 nS
- Phase Synchronization :0 to 360 Degrees, 1 Degree Step
- Trigger :Automatic, Manual, External
- Source Impedance :50 Ohms
- Dimensions :19 inch /22U
- Applications :Communication, Telecom, Medical, Broadcast and TV, Railway, Information Technology, Military, Aviation, New Energy Electrical Power
- Operating Temperature :15 to 35 Degree C
- Weight :100 kg
