DMC MIL-STD 461

Anechoic Chamber by Diamond Microwave Chambers (7 more products)

Note: Your Quotation Request will be directed to Diamond Microwave Chambers.

The DMC MIL-STD 461 from Diamond Microwave Chambers is a Anechoic Chamber with Frequency 30 MHz to 40 GHz. More details for DMC MIL-STD 461 can be seen below.

Product Specifications

Product Details

Part Number
DMC MIL-STD 461
Manufacturer
Diamond Microwave Chambers
Description
Semi Anechoic Chamber Referred as MIL STD Chamber

General Parameters

Type

Semi Anechoic
Frequency

30 MHz to 40 GHz
EMC Standards

MIl-STD 461E, MIl-STD 461F, MIl-STD-461G, ANSI C63.4, CISPR-16, IEC/EN 61000-4-3
Radiated Emissions Compliance

ANSI C63.4, CISPR-16
Radiated Immunity Compliance

IEC/EN 61000-4-3
Absorber

Ferrite Tiles, Polypropylene
Application Industry

Ground Plane
External Dimensions

5.5 x 5.5 x 3.5 m (L x W x H)
Note :

Load Capacity : 1500 Kg
