CDN S502A
Coupling Decoupling Network by AMETEK CTS GmbH (150 more products)
Request Quote
Note: Your Quotation Request will be directed to AMETEK CTS GmbH.
The CDN S502A from AMETEK CTS GmbH is a Coupling Decoupling Network with Frequency 150 kHz to 6 GHz, Operating Voltage 2.5 KVDC, EUT Current 1 A. More details for CDN S502A can be seen below.
Product Specifications
Product Details
- Part Number :CDN S502A
- Manufacturer :AMETEK CTS GmbH
- Description :Coupling Decoupling Network for IEC 61000-4-6, type S1, 230 MHz (N 50 Ω), double screened
General Parameters
- Frequency :150 kHz to 6 GHz
- Cable Type :Screened
- EMC Standards :IEC/EN 61000-4-6, CISPR 22, CISPR 24, CISPR 32, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4, IEC 60533, IEC 60601-1-2, IEC 61326
- 3 dB Bandwidth :2 GHz
- Common Mode Impedance :150 Ohms
- Decoupling Attenuation :40 to 60 dB
- Voltage Division Factor :10 dB
- RF Test Voltage :5 kVDC
- Operating Voltage :2.5 KVDC
- EUT Current :1 A
- Dimensions :100 x 100 x 240 mm
- Connectors :BNC
- Connector AE :N Type
- Connector EUT :N Type
- Weight :1.5 kg
